2.100-2.500 Kg/Month
Coffee Roaster Machine
Artisan - Coffee Roaster Machine
PRATTER 5.0
PRATTER 5.0
COFFEE ROASTER MACHINE
5.0 Kg/batch



TECHNICAL SPECIFICATION
Class | Shop Series |
Minimum Batch Capacity | 2.000 gr |
Maximum Batch Capacity | 5.000 gr |
Heating Source | LPG |
Burner | Atmospheric Burner - Polidoro 24 kW |
Burner Control | 0-100% by 0-15 Mbar with dial pressure gauge |
Drum | Cast Iron with Special Treatment |
Temperature Display Control | Beans Temperature (BT) & Environment Temperature (ET) |
Airflow | Variable Speed by Inverter Speed Control |
Machine Dimension | 2.100 x 1.800 x 2.000 mm |
Weight | 500 Kg |
Power Source | 1.000 Watt / 220 Volt |
Data Logging | RS485/ Modbus RTU |
OPTIONAL - PLC SERIES
Featuring a 7-inch touchscreen, Ethernet PC communication, and playback support for Artisan, Cropster, and more. The looping system burner out of pressure TM ensures precise heat control for optimal roasting.


Capacity
5.000 gr/batch


Burner
Polidoro - 24 kW


Power
220V/1000W


Roasting Time
8-15 Min


(L x W x H) mm
2.100 x 1.800 x 2.000 mm


Weight
500 Kg
Pratter 5.0
Custom Configurator
Try to Custom Pratter 5.0 with machine configurator
Color, Wood Material and Logo Placement


CAST IRON SOLID DRUM
Solid drum type, with special alloy cast iron. Additional treatment excellent heating and keep cleanest aroma and zero contaminate.
POLIDORO BURNER
Using special Blue-flame Gas Burner support by POLIDORO-Italy. Low emission, noise level and stable flame for heating and roasting process.






SUMITOMO ELECTRIC MOTOR DRIVES
Driver motor one line to drum roasting High efficiency, low maintenance, and low friction and silent run. Support by SUMITOMO DRIVES TECHNOLOGIES-Japan.


Pratter 5.0 Video
Machine Detail
PRATTER is one of the brands of coffee processing products from Indonesia. PRATTER currently has a Coffee Bean Processing Machine, namely PRATTER COFFEE ROASTER MACHINE with several types Included with the Electrical airflow control, drum speed control and burner control. Pratter 5.0 series can be controlled in two different ways. Manually via the control panel or semi-automatically via Roasting Scope / Data Logging Software.
Roasting is the process of changing coffee beans from green beans to roasted beans. One of the important processes in coffee processing because this process will affect the quality of the aroma and taste of coffee.
Each coffee bean from various regions, of course, has a distinctive taste and aroma. This roasting process will strengthen the taste and aroma of each processed coffee bean.
PRATTER Coffee Roaster Machine Pratter 5.0 is a coffee roaster machine with a capacity of 5.0 kg / batch. The three key points of this process are:
- Coffee Bean
- Heating System
- Roasting Process Support
PRATTER COFFEE ROASTER MACHINE with several types of variants using 220V power and LPG gas as a burner supply can be your choice to start and develop a coffee bean processing business.
PRODUCT SUPPORT & WARRANTY
- Pratter Machine Warranty e-Centificate
- 5 Years Warranty Cast Iron Special Surface Treatment
- 1 Year Electrical & Parts Warranty
- 1 Year Service Warranty
- Basic Maintenance Training
- Manual Book and Instalation Guide
- Intermediate Roasting Training ( Optional )
